LARGE ROLLER
Quick Overview of STORIKE Heavy Duty Roller Catalog
Service
-On-time Delivery
-Quality Assurance (one year)
-Customized Services (logo,packaging,graphic,etc.)
Contact Information
-Number:+86-13963746955
-Email:[email protected]
- Overview
- Recommended Products
Product Description
Storike is a professional manufacturer specialized in road rollers, providing comprehensive OEM and ODM services.
We produce large single-drum rollers ranging from 4 tons to 12 tons, and offer customized solutions to meet diverse customer demands. A wide selection of gasoline and diesel engines is available, including renowned brands such as Honda, Yanmar, Kubota, Cummins, Changchai, among others.
Customers can choose between padfoot drums and smooth drums, as well as optional configurations with or without a cab or sunshade.
All our products are backed by a one-year warranty. We guarantee a prompt response upon receiving your inquiries. Should you have any requirements, please feel free to contact us.
| Picture |  |
 |
 |
 |
 |
| Model | STS04 | STS06 | STS08 | STS10 | STS12 |
| Operating weight(KG) | 40000 | 5800 | 7850 | 9600 | 11950 |
| Static line load(N/CM) | 125 | 165 | 225 | 225 | 310 |
| SIZE(MM)L*W*H | 4040*1430*2520 | 4550*1760*2725 | 4820*1765*2645 | 5065*2020*2720 | 5920*2260*2950 |
| Drum width(MM) | 1300 | 1500 | 1600 | 1800 | 2100 |
| Drum diameter(MM) | 1000 | 1150 | 1200 | 1250 | 1500 |
| Engine |
Changchai/ Yanmar/ Kubota |
Changchai/ Yanmar |
Cummins/ Changchai |
Cummins | Cummins |
| output power(KW) | 36/34.5/33.6 | 68/54.1 | 74/68 | 74 | 93 |
| Rotational speed(rpm) | 2400/3000/2400 | / | 2200/2400 | 2200 | 2200 |
| Electrical equipment(V) | 12 | 24 | 24 | 24 | 24 |
| Speed(KM/H) | 0-7.5 | 0-9 | 0-9.5 | 0-10 | 0-10 |
| Theoretical climbing ability | 30% | 30% | 30% | 30% | 30% |
| Vibration frequency(HZ) | 54 | 45 | 52 | 50 | 28/32 |
| Vibration amplitude(MM) | 0.5 | 0.5 | 0.5 | 0.5 | 1.7/0.8 |
| Excitation force(KN) | 70 | 85 | 118 | 150 | 260/160 |
| Lubricating oil(L) | 12 | 12 | 15 | 15 | / |
| Hydraulic oil(L) | 63 | 115 | 120 | 125 | 135 |
| Fuel capacity(L) | 76 | 95 | 140 | 154 | 165 |
