STORIKE LIGHT TOWER
Quick Overview of STORIKE Mobile Light Tower Catalog
Service
-On-time Delivery
-Quality Assurance (one year)
-Customized Services (logo,packaging,graphic,etc.)
Contact Information
-Number:+86-13963746955
-Email:[email protected]
- Overview
- 4.6 Meters
- 5 Meters
- 7 Meters
- 9 Meters
- Recommended Products
Storike is a professional manufacturer specializing in lighting towers, providing comprehensive OEM and ODM services.
We produce lighting towers ranging from 5 meters to 9 meters, and offer customized solutions to meet diverse requirements. Customers can choose from gasoline-powered, diesel-powered, or solar-powered lighting towers.
All products come with a one-year warranty. We guarantee a prompt response upon receiving your inquiry. Please feel free to contact us for further assistance.
|
4.6 Meters Airport Light Tower Click on the picture - view the details |
| Picture |  |
||
| Model | 4TN4000B | ||
| Engine & Power | YANMAR 3TNV76 10.7KW |
CHANGCHAI 3M78 11.5KW/ CHANGCHAI CZ380Q 14.3KW |
|
| Engine Type | Three cylinder,water-cooled,four stroke | ||
| Frequency | rpm | 1500 | |
| Generator standard configuration | XINGNUO | ||
| Rated voltage (50/60hz) | V | 230/240-120 | |
| Motor insulation class | CLASS H | ||
| Motor protection class | lP23 | ||
| Headlights | LED light (yellow/white optional) | ||
| Luminous flux | lm | 140000 | |
| Number&power of lamps | w | 17*48 | |
| Fuel tank capacity | L | 90 | |
| Continuous working time | h | 80 | |
| Maximum wind resistance speed | m/s | 20 | |
| Noise level | dB | 72 decibels at 7 meters | |
| Maximum lift height | m | 4.6 | |
| Tire size | M | 14 | |
| Maximum traction speed | km/h | 100 | |
| L*W*H | mm | 3300*2400(Expand4350)*2000(Expand4600) | |
| Weight | kg | 1100 | |
|
5 Meters Hand-push type light tower Click on the picture - view the details |
| Picture |  |
 |
 |
| Model | SMLV400A/B | SMLV1000A/B | SMLV1000QA |
| Gasoline generator | HONDA EC4000CX/ LONCIN LC3500 |
HONDA EC4000CX 3KW/ HONDA EC5000CX 5KW |
HONDA EC4000CX/LONCIN LC3500 |
| Diesel generator | ANMAX DG3500CLE | ANMAX 3KW/ ANMAX 5KW |
ANMAX DG3500CLE |
| Rated Voltage | 220V | 220V | 220V |
| Continuous Work Time | 13H | 13H/11H | 13H |
| Fuel Tank Capacity | 25L | 24L/25L | 25L |
| Headlights |
Metal Halide/ LED lamp |
Metal Halide/ LED lamp |
Metal Halide |
| Power | 400W*2 or 400W*4/ 200W*2 or 200W*4 |
1000W*2 or 1000W*4/ 200W*2 or 200W*4 |
1000W*2 |
| Luminous flux | 72000 or 144000lm/ 56000 or 112000lm |
220000 or 440000lm/ 56000 or 112000lm |
220000lm |
| Light stand retractable | 1700-5000mm | 1700-5000mm | 1700-5000mm |
| Lifting Method | Hand lift | Hand lift | Hand lift |
| Wind Resistance | <6 | <6 | <6 |
| Weight | 112KG/116KG | 114KG/120KG | 117KG |
|
7 Meters Trailer Mobile Light Tower Click on the picture - view the details |
| Picture |  |
 |
 |
| Model | 4VA4000 | 4EVA4000 | 4TNVE600 |
| Engine Brand | Kama/Changchai | Changchai | / |
| Power(KW) | 6 | 6 | Battery capacity:6*200AH |
| Frequency(HZ) | 50 | 50/60 | / |
| Rotating speed(rpm) | 3000 | 3000/3600 | / |
| Rated voltage(V) | 230 | 230 /240-120 VAC | DC24V |
| Continuous working(h) | 28 | 25 | 8 TO 12 |
| Fuel tank capacity(L) | 38 | 38 | / |
| Lamps power*quantity(W) | 1000W*4||400W*4 | 1000W*4||400W*4 | 150W*4 |
| Luminous flux(lm) | 440000||224000 | 440000||224000 | 21000*4 |
| Headlights |
Metal Halide Flood Lights/ LED lamp |
Metal Halide Flood Lights/ LED lamp |
LED light |
| Lifting method | manual lift | electric lift | manual/electric lift |
| size(mm) | L2180*W1130*H2700 | L2180*W1130*H2700 | L3200*W1630*2750 |
| Lift height(meter) | 7 | 7 | 7 or 9 |
| Weight(KG) | 550 | 550 | 1180 |
|
9 Meters Trailer Mobile Light Tower Click on the picture - view the details |
| Picture |  |
 |
 |
 |
| Model | 4TN4000 | 4TNVH1600 | 4HVP1600 | 4HVP1600M |
| Engine Brand |
Changchai/ Yanmar/Kubota |
Kubota |
kubota/Yanmar/ Changchai |
kubota/Yanmar/ Changchai |
| Power(KW) |
11.5/14.3// 10.7//12.6 |
4.8//12.6 |
12.6/10.7// 11.5/14.3 |
12.6/10.7// 11.5/14.3 |
| Frequency(HZ) | 50//60 | 60 | 50/60 | 50/60 |
| Rotating speed(rpm) | 1500 | 1800 | 1500 | 1500 |
| Rated voltage(V) | 230/240-120 | 240V | 230/240-120 | 230/240-120 |
| Continuous working（h） | 80 | 60 | 65 | 65 |
| Fuel tank capacity（L） | 110 | 100 | 90 | 90 |
| Lamps power*quantity |
1000W*4 400W*4 |
400W*4 |
1000W*4 400W*4 |
1000W*4 400W*4 |
| Luminous flux(lm) |
440000 224000 |
360000 |
440000 224000 |
440000 224000 |
| Headlights |
Metal Halide Flood Light/ LED lamp |
LED lamp |
Metal Halide Flood Light/ LED lamp |
Metal Halide Flood Light/ LED lamp |
| Lifting method | Manual lift | Electrical Self-lifting | Hydraulic lift | Hydraulic lift |
| size(mm) | L4400*W1670*H1830 | L2450*W1350*H2650 | L4100*W2400*H24880 | L4100*W2400*H24880 |
| Lift height(M) | 9 | 9 | 9 | 9 |
| Weight(KG) | 980 | 860 | 1360 | 1360 |
